Máy bơm chống ngập úng kiểu dã chiến kiểu SERIES® 10

31.10.2018 2144 lượt xem

Self-Priming Pumps- 10 SERIESÂ® (ENGINE DRIVEN) (MÃY BÆ M CHá»NG NGáº¬P ÃNG KIá»U DÃ CHIáº¾N (HOáº¶C KIá»U DI Äá»NG)

Thông số kỹ thuật chi tiết: Máy bơm chống ngập úng kiểu dã chiến kiểu SERIES® 10 :

Models: 12D-1B20 FT4 ; 12D-GX160 ; 12D1-1B20 FT4 ; 12D1-GX160 ; 12E1-GX160 ; 13A52-GX390 ; 13D-GX270 ; 13D-L70EE ; 13D-L70W FT4 ; 13D-L70W FT4 S/G ; 13D1-GX270 ; 13D1-L70EE ; 13D1-L70EE S/G ; 13D1-L70W FT4 ; 13D1-L70W FT4 S/G ; 13E2-12LD477 S/G ; 13E52-GX390 ; 13G1-1B20 ; 13G1-GX160 ; 14C2-F3L ; 14C2-QSF2.8P FT4 ; 14C20-F3L ; 14C20-QSF2.8P FT4 ; 14D1-CH23 S/G ; 14D1-GX390 ; 14D2-12LD477 S/G ; 14D52-12LD477 S/G ; 14D52-1B50 FT4 S/G ; 14D52-CH23 S/G ; 14D52-GX390 ; 16A2-4045T ; 16A2-F3L ; 16C2-4045T ; 16C2-F4L ; 16C2-F5L ; 16C2-QSF2.8P FT4 ; 16C20-4045T ; 16C20-F4L ; 16C20-F5L ; 16C20-QSF2.8P FT4 ; 16D60-F3L ; 16D60-QSF2.8P FT4 ; 112D60-B-TCD914L6

MODELS:

Item	Size	Casing	Impeller / Rotor	Drive	Flange	Seal
12D-1B20 FT4	2 x 2	Aluminum	Cast Iron	Diesel Engine	NPT	Double Grease
12D-GX160	2 x 2	Aluminum	Ductile Iron	Gasoline Engine	NPT	Double Grease
12D1-1B20 FT4	2 x 2	Aluminum	Ductile Iron	Diesel Engine	NPT	Silicon Carbide
12D1-GX160	2 x 2	Aluminum	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
12E1-GX160	2 x 2	Aluminum	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
13A52-GX390	3 x 3	Cast Iron	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
13D-GX270	3 x 3	Aluminum	Ductile Iron	Gasoline Engine	NPT	Double Grease
13D-L70EE	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Double Grease
13D-L70W FT4	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Double Grease
13D-L70W FT4 S/G	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Double Grease
13D1-GX270	3 x 3	Aluminum	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
13D1-L70EE	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Silicon Carbide
13D1-L70EE S/G	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Silicon Carbide
13D1-L70W FT4	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Silicon Carbide
13D1-L70W FT4 S/G	3 x 3	Aluminum	Ductile Iron	Diesel Engine	NPT	Silicon Carbide
13E2-12LD477 S/G	3 x 3	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
13E52-GX390	3 x 3	Cast Iron	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
13G1-1B20	3 x 3	Aluminum	Cast Iron	Diesel Engine	NPT	Silicon Carbide
13G1-GX160	3 x 3	Aluminum	Cast Iron	Gasoline Engine	NPT	Silicon Carbide
14C2-F3L	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
14C2-QSF2.8P FT4	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
14C20-F3L	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
14C20-QSF2.8P FT4	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
14D1-CH23 S/G	4 x 4	Aluminum	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
14D1-GX390	4 x 4	Aluminum	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
14D2-12LD477 S/G	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
14D52-12LD477 S/G	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	NPT	Silicon Carbide
14D52-1B50 FT4 S/G	4 x 4	Cast Iron	Ductile Iron	Diesel Engine	None	Silicon Carbide
14D52-CH23 S/G	4 x 4	Cast Iron	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
14D52-GX390	4 x 4	Cast Iron	Ductile Iron	Gasoline Engine	NPT	Silicon Carbide
16A2-4045T	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
16A2-F3L	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
16C2-4045T	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
16C2-F4L	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
16C2-F5L	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
16C2-QSF2.8P FT4	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Double Grease
16C20-4045T	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
16C20-F4L	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
16C20-F5L	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
16C20-QSF2.8P FT4	6 x 6	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
16D60-F3L	6 x 6	Cast Iron	Cast Iron	Diesel Engine	NPT	Silicon Carbide
16D60-QSF2.8P FT4	6 x 6	Cast Iron	Cast Iron	Diesel Engine	NPT	Silicon Carbide
112D60-B-TCD914L6	12 x 12	Cast Iron	Ductile Iron	Diesel Engine	NPT	Tungsten Carbide
