Máy bơm chìm SERIES S (WIDEBASE SUBMERSIBLE) (Submersible Pumps (60 Hz))

30.10.2018 1168 lượt xem

S Series (Widebase Submersible)Submersible Pumps

Thông số kỹ thuật chi tiết: Máy bơm chìm SERIES S (WIDEBASE SUBMERSIBLE) (Submersible Pumps (60 Hz)):

Model: S8D1-E275 460/3 ; S2A1 115V 1P ; S2A1 230V 1P ; S3A1 230V 1P ; S3A1 230V 3P ; S3A1 460V 3P ; S3A1-E5 200/3 ; S4A1-E25 460/3 ; S4B1-E50 460/3 ; S6A1-E60 460/3 ; S6B1-E95 460/3 ; S6B1-E95 575/3 ; S6C1-E35 460/3 ; S8A1-E95 460/3 ; S8A1-E95 575/3 ; S8B1-E100 460/3 ; S8B1-E100 575/3 ; S8C1 460V 3P ; S8C18-E140 460/3 ; S12A1-E140 460/3.

MODELS:

Item	Size	Casing	Impeller / Rotor	Drive	Flange	Seal
S8D1-E275 460/3	8	Ductile Iron	Ductile Iron	Electric Motor	NPT	Silicon Carbide
S2A1 115V 1P	2 x 2	Ductile Iron	Ductile Iron	Electric Motor	NPT	Carbon/Ni-Resist
S2A1 230V 1P	2 x 2	Ductile Iron	Ductile Iron	Electric Motor	NPT	Carbon/Ni-Resist
S3A1 230V 1P	3 x 3	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S3A1 230V 3P	3 x 3	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S3A1 460V 3P	3 x 3	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S3A1-E5 200/3	3 x 3	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S4A1-E25 460/3	4 x 4	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S4B1-E50 460/3	4 x 4	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S6A1-E60 460/3	6 x 6	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
S6B1-E95 460/3	6 x 6	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S6B1-E95 575/3	6 x 6	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S6C1-E35 460/3	6 x 6	Ductile Iron	Ductile Iron	Electric Motor	NPT	Tungsten Carbide
S8A1-E95 460/3	8 x 8	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
S8A1-E95 575/3	8 x 8	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
S8B1-E100 460/3	8 x 8	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
S8B1-E100 575/3	8 x 8	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
S8C1 460V 3P	8 x 8	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
S8C18-E140 460/3	8 x 8	CD4MCu	CD4MCu	Electric Motor	None	Tungsten Carbide
S12A1-E140 460/3	12 x 12	Ductile Iron	Ductile Iron	Electric Motor	None	Tungsten Carbide
